Ashwin Lewis
The Sleep/Wake button on the iPhone 6 is located on the right side of the device. When you're not using your phone, pressing this button locks it, putting the display to sleep, saving battery, and preventing accidental touches. If your Sleep/Wake button is not working, it could be due to a few reasons. It may be that the flex cable connected to the home button is damaged, or that the button's spring action has been affected.
| Characteristics | Values |
|---|---|
| Location of Sleep/Wake button | On the right side of the iPhone 6 |
| Function of Sleep/Wake button | Locks the iPhone, puts the display to sleep, saves battery, prevents accidental touches |
| Troubleshooting a non-functional Sleep/Wake button | Check if the flash works, disconnect and reconnect the home button flex cable, reset the device via iTunes |
| Potential causes of a non-functional Sleep/Wake button | Damage to the flex or button during screen replacement, issues with the spring-type mechanism |
Explore related products
What You'll Learn
Try disconnecting and reconnecting the home button flex cable
If your iPhone 6 sleep/wake button is not working, one possible solution is to disconnect and reconnect the home button flex cable. This process involves opening up your iPhone and accessing internal components, so proceed with caution and ensure you have the necessary tools and knowledge before attempting any repairs.
To begin, power off your iPhone and remove the two 3.6mm-long P2 Pentalobe screws located next to the Lightning connector. Then, use a suction cup and a hard plastic plectrum to lift the front screen. It is recommended to use tape over the screen to protect against small glass splinters. Place the suction cup on the display, directly above or next to the Home button.
With the screen lifted, open the iPhone by swinging the home button end of the front panel assembly away from the rear case, using the top of the phone as a hinge. Several clips along the top edge of the front panel form a partial hinge. Prop up the display at a 90-degree angle and secure it with a rubber band to avoid strain on the display cables.
Now you can access the internal components. Remove the metal battery connector bracket and the front panel assembly cable bracket from the logic board. Make sure to keep track of each screw and store them safely to avoid mixing up parts.
To disconnect the home button flex cable, use a spudger or your fingernail. Gently lift the cable connector from the logic board, being careful not to pry on the sockets. Before disconnecting or reconnecting the cable, ensure the battery is disconnected for safety.
After making the necessary adjustments, carefully reassemble your iPhone in the reverse order, ensuring that cables are properly connected and no parts are pinched. Power on your device and test the sleep/wake button to see if the issue has been resolved.
Troubleshooting Pixel XL3 That Won't Wake From Sleep
You may want to see also
Explore related products
Check if the power button mechanism is damaged
If your iPhone 6 sleep/wake button is not working, it could be due to a damaged power button mechanism. Before attempting any repairs, it is important to discharge the battery below 25% and power off your iPhone to avoid any risk of battery explosion or damage to your device.
To check if the power button mechanism is damaged, you can start by examining the button itself for any physical damage, such as scuffs or stuck debris. If the button appears intact, the next step is to carefully open your iPhone and inspect the internal components. This process requires a plastic opening tool and a spudger or similar tools. It is crucial to keep track of each screw removed and to be cautious around the logic board to avoid permanent damage.
Once inside, you can inspect the power button mechanism, which includes the power button cable and the physical part that clicks when pressed. Look for any signs of damage, corrosion, or debris. If you notice corrosion, cleaning the affected area with isopropyl alcohol and a toothbrush may resolve the issue. Additionally, you can refer to repair guides to identify the specific components related to the power button, such as the power button flex cable and the logic board.
If you are unable to identify any obvious damage, you may need to consult a micro-soldering repair specialist to diagnose and repair the issue. They will have the necessary skills and tools to probe the circuit and perform complex repairs.
Sleep-Wake Button on iPhone 5s: Where is it?
You may want to see also
Explore related products
Try a new flex
If your iPhone 6 sleep/wake button is not working, you may want to try a new flex. The power button and flash are on the same flex. Normally, changing a screen should not have any interaction with the power button connector or flex, and none of the circuitry is accessible during a normal screen replacement. However, it is possible that your screwdriver may have slipped and damaged the flex or button.
You can try disconnecting and reconnecting the home button flex cable located directly above the battery beneath a metal shield. Before doing so, you may want to look at the power button from inside the phone with a magnifying glass or jeweler's loupe to see if the mechanism has been damaged. If you notice any tears in the flex cable, you may need to replace the entire flex assembly.
If you have already replaced the flex cable and the issue persists, you may want to rule out a parts issue with the power flex by putting your logic board in another iPhone 6 housing to test, or by ordering a second power flex and connecting it to the connector to test. Additionally, check for any minor water damage around the connector.
Sleep Solutions: Peaceful Rest Without Disturbing Your Spouse
You may want to see also
Explore related products
Reset your device via iTunes
If your iPhone 6 sleep/wake button is not working, you can try to reset your device via iTunes. This method reinstalls the software on your device and restores it to its default settings.
To reset your iPhone 6 via iTunes, you will need to first connect your device to a computer. You can use a USB or USB-C cable, or a Wi-Fi connection. Make sure that iTunes is updated to the latest version.
Once your device is connected, open the iTunes app on your computer. In the iTunes window, click the Device button near the top left. From here, you can reinstall the software on your device and restore it to its default settings.
It is important to note that restoring your iPhone will delete all your information and settings. However, iTunes will back up your device before restoring it, so you can use the backup to restore your device to how it was previously.
Before restoring your device, you may want to save the information on your iPhone by making a backup. To do this, go to Settings > [your name] > Find My, tap Find My iPhone, then turn it off.
Muscle Soreness: Can It Interrupt Your Sleep?
You may want to see also
Explore related products
$14.59 $21.99
$12.34 $17.99
Check if the flash works
If your iPhone 6 sleep/wake button is not working, it is worth checking if the flash works, as the power button and flash are on the same flex.
To check if the flash works, open the Camera app and tap the flash button to choose a different setting. If the flash works only sometimes, you can try cleaning the camera lenses with a microfiber cloth. If you use a lens converter, metallic case, or a magnetic lens mount, try removing the accessory.
If the flash is still not working, you could try resetting your iPhone via iTunes. This will erase all your iPhone data, so make sure to back up your content first. To do this, update iTunes to the latest version, open it, and connect your iPhone to your computer. When the device is connected, click to trust the computer. From the Summary tab, choose the 'Restore iPhone' option from the right side of the interface, and then click 'Restore and Update'. iTunes will then ask you to choose the firmware file you downloaded for fixing.
If the flash still doesn't work, you may need to service your iPhone.
Adjusting Sleep-Wake Cycles: Simple Strategies for Better Sleep
You may want to see also
Frequently asked questions
Try disconnecting the battery and reconnecting it. If that doesn't work, try resetting your device via iTunes.
The screwdriver might have slipped and damaged the flex or button. Try to remember if that happened and inspect the button with a magnifying glass.
Try disconnecting and reconnecting the home button flex cable located directly above the battery beneath a metal shield.
When you're not using your iPhone, press the Sleep/Wake button to lock it. This puts the display to sleep, saves the battery, and prevents accidental touches.
On the iPhone 6, the Sleep/Wake button is on the right side of the phone.
